YES-EU 40/1 · Wall-Mounted
As Europe accelerates its transition to new energy solutions, space-efficient charging infrastructure is essential for commercial facilities, logistics hubs, and private garages. This is an extremely compact and affordable fast-charging solution engineered by experts to meet the growing demands of the European EV market. Delivering reliable DC power directly to the battery, this unit bypasses onboard converters to provide fast, efficient energy delivery while taking up minimal physical space.
-
Universal EV Charging
Delivers a broad 200–1000 VDC output to seamlessly charge all modern and high-voltage electric vehicles.
-
Space-Saving & Flexible
Weighing just 40 kg, this compact unit maximizes facility space by mounting easily on walls, columns, or a portable wheeled stand.
-
Smart Remote Control
Fully integrated with OCPP 1.6 (JSON) via 4G and Ethernet for effortless, real-time fleet management across European networks.
-
All-Weather Durability
Built for tough European climates with an IP54-rated enclosure, operating reliably indoors and outdoors from -20°C to +50°C.
YES-EU 40/1 · Wall-Mounted — full specification
| Specification | Value |
| Charging power | 40 kW (48 A DC max) |
| Output voltage range | 200–1000 Vdc |
| Supply voltage | 400 Vac |
| Max input current | 62 A |
| Charging standard | IEC 61851-1 / -23 |
| Connector | 1 × CCS2 · 5 / 7 m |
| Interface | 7" colour touchscreen · RFID |
| Communication | 4G · Ethernet |
| Smart control | OCPP 1.6J |
| Operating temp | −20 °C to +50 °C |
| Protection | IP54 |
| Dimensions (W×D×H) | 800 × 170 × 550 mm |
| Weight | 40 kg |
| Mounting | Wall, column, or optional wheeled unit |
